SHIPPING AND HANDLING
- 22 -
COROB™ D600 - D700 - D800TX
3. Remove machine wrapping. Take out any accessories and/or material supplied with the machine.
DANGER
Should the machine appear damaged during shipping, do not attempt to start it and contact the authorized
technical service or dealer.
4. Loosen all screws A holding the brackets to the machine.
5. Lower the feet (chapter 4.2.1) so that the machine is slightly raised from the wooden beams on which it
rests.
6. Remove the wooden beams B.
7. Completely unscrew and remove all screws and nuts fastening each bracket C to the pallet.
8. Raise the feet (chapter 4.2.1) until when the machine can move easily on its wheels.
9. Lower both platforms.
10. Grasp the machine on the sides (this must be done by at least two people) then slide it slowly along the
platforms on its wheels, then lower it to the ground.
1 2 3
