FEATURES
- 10 -
COROB™ D600 - D700 - D800TX
2.2 Description of units
Canisters
The machine canisters can be of different capacities and are suitable for containing
the product to be dispensed. Covers in the upper part of the machine provide
access for lling the canisters. Each canister has its own lid.
MAX
Nozzle Center
The ends of the dispensing pipes coming from the canisters converge and are xed
to the nozzle center, from which the tinting product to ll the can is dispensed.
Shelf
The can shelf allows for the correct positioning of the can under the dispensing
nozzles.
The Automatic shelf is managed by the computer that controls its
movement and checks that the can placed on it is actually the one selected
for dispensing. A photocell checks for the presence of the can and that the
shelf is correctly positioned.
The Semiautomatic shelf is commanded by the operator with the activation
buttons (two-handed control); the shelf stops when the can is detected by
the photocell.
Tipping panel roll conveyor system
An optional system made up of tipping panel roll conveyors is available to facilitate
the loading of cans; the conveyors are xed to the front panels of the machine
and allow heavy cans to be eased as far as the shelf.
