ORDINARY MAINTENANCE
- 46 -
COROB™ D600 - D700 - D800TX
4. Rotate and pull down tool A, so as to remove puncher B, then separate the puncher from the tool.
5. If necessary, clean the surfaces of the puncher to remove encrusted matter, using a product compatible with
the type of bases used in your system. We recommend lubricating the puncher walls with a common, non-
contaminant lubricant (ENOTAP or similar).
6. Reassemble the puncher following the above steps in reverse order.
7. Connect power supply and switch on the machine (chapter 5.3).
If the can punching is inadequate because the cutting edge of the puncher is excessively worn, replace the worn
puncher.
7.8 Relling the humidier system bottle
WARNING
When the water in the bottle reaches the minimum level, ll up immediately.
1. Disconnect power supply (chapter 5.6).
2. Open the machine upper cover where the bottle is located.
3. Unscrew the bottle cap and add water (1 Pint / 0.5 liters maximum), paying attention NOT TO EXCEED THE
MAXIMUM LEVEL.
To reduce the risk of lime encrustations due to hard water, it is recommended to use distilled water.
4. Replace the cap and rmly tighten.
5. Close the upper cover, connect power supply and switch on the machine (chapter 5.3).
2 3
MAX
MIN
5
0
0
m
l
1
P
i
n
t
MAXMAX
MIN
MIN
