5.6.4.1. ADJUSTINGTHEPOSITIONWHERETHEPRODUCTDROPSONTOTHESPREADERDISCS

For all operation s, use the PPE (Personal Protective Equipmen) described below: 



Protectivegloves


Safetyshoes


Workoveralls

Proceedasfollows:

STEP OPERATION IMAGE




V 

1
s Releasetheadjustmentleverbyunscrewingthe
handwheel(V).










s Movethe droppoint lever (DP) towards 
settings(a,b,c...)onthegraduatedindex (IG)
IG

to increase the quantityof fertilizer spread in
thecentre. 
s Locktheadjustmentleverbytighteningthe
DP

handwheel (V) . 



2 



s Movethe droppoint lever (DP) towards 
settings(u,v,z...)onthegraduatedindex (IG)
IG

to decrease the quantity of fertilizerspread 
inthecentreandincreasethequantityatthe
edges. 
DP
s Locktheadjustmentleverbytighteningthe 
handwheel (V) . 
05‐HANDLINGANDINSTALLATION
