TWIN DISC CENTRIFUGAL FERTILIZER SPREADER - CX 1500/2150/2400/2800/3200
4-12





4.6. CONTROLDEVICES

Themachineismadeupofthefollowingcomponents: 
POS. DEVICE NOTES

A
Hydraulic control for open in g and closing the fe rtilizer outlets 
(STANDARD)
Positionedatthefrontofthemachine
(hydraulichoses). 

B
Manualdosingcontrol Positionedatthesideofthemachine. 


C
Electronic dosing control (OPTIONAL) Positionedatthesideofthemachine. 

WARNING!
Danger due to closing of the shutter on the metering device,with the risks of crushing and/or
cuts.
When pressurised oil is delivered to the hydraulic control,the shutter on the metering device
closes.
NEVERPLACELIMBSORANYBODYPARTSINTHEAREAUNDERNEATHTHEHOPPERORNEARTHE

METERINGDEVICEANDTHESHUTTER.
DURINGMAINTENANCE,SWITCHOFFTHETRACTORANDMAKESUREITCANNOTBESTARTEDBY
OTHERPEOPLE.REMOVETHEKEYFROMTHEIGNITION.

D
Tiltindicator. 

E
Adjustmentoffertilizerfallontothespreaderdiscwithgraduated
indicesforfertilizingwithmaximumprecision. 
Positionedatthesideoftheframe. 

Situated above the distributor assembly at the
rearofthemachine. 


F
Distributor blade adjustment. 
Situated on the distributor assembly at the rear
ofthemachine. 











A‐B CX (STANDARD) C CX (OPTIONAL)
D E F
