5.2.1. ASSEMBLINGTHEHOPPERSIDESANDEXTENSIONS

For all operations, use the PPE (Personal Protective Equipmen) described below: 





Protectivegloves




Safetyshoes




Workoveralls

Proceedasfollows:

STEP OPERATION IMAGE






1 





s






Applytheadhesivegasketsuppliedalongthetop
perimeterofthehopper. 








2 





s






Fitthelongerextensionstothehopperandsecure
them in place,withoutfully tightening the bolts. 








3 



s


s
s



Theheadsoftheboltsmustbeontheinsideof
the hopper,while the washer and the nut should
betightenedfromtheoutside. 
Tightenalltheboltssoastosecuretheextensions
tothehopper.
Makesurethatalltheboltsarefullytightened. 

