DANGER!
Mechanicaldangerduetoraising/loweringthemoveablelimiter,withtherisksofcrushing,cuts,
amputation,entrainment,entrapmentandimpact.
Keepasafedistanceawayfromthemachine.

5.6.6. ADJUSTINGTHEMOBILEFOCUSERFORBOUNDARYSPREADING(optional)


Proceedasfollows:

STEP OPERATION IMAGE

s Hydraulicallylowerthelimiter. 
§“5.2.3.HYDRAULICCONNECTIONS”on
page5‐11 
s Switchoffthetractor’sengineandremovethe 
1
keysfromtheignition. 
s Blockthevehiclecomprisingthetractorandthe 
machine to avoid accidental movement when
workingonthemachine.
s Makesureallofthemovingpartsonthemachine
havestopped.



Adjust the limiter according to the fertilizer trajectory: 
s Loosenthehandwheels (V) . 
s Adjustthelimiteronthespreaderdisc 
s Tightenthehandwheels (V) . 
2 
V 
Runaspreadingtestswiththelimiteractive, 
otherwise repeat the adjustment with the machine off. 
§“5.2.8.MOBILEFOCUSERFORBOUNDARY
SPREADING(Optional)”onpage5‐28







3
s Afterspreadingontheedgesofthefield,raisethe
limiterandcontinuewithnormalspreading.

V 
