CAUTION!
Thisoperationmustonlybeperformedbyspecialistmaintenancetechnicians!
Toavoid accidents and situationsofdanger,alltheoperations must onlybe carried outby one
maintenancetechnicianalone.
Keeppeopleandanimalsawayfromthedangerzonebehindandunderneaththemachine.

DANGER!
Dangerof lacerationsorentrapment dueto accidentalcontact with the machine’smechanisms
duringtheoperations.
Keeppeopleandanimalsawayfromthedangerzonebehindandunderneaththemachine.

5.2.4. SPREADER DISCS



For all operation s, use the PPE (Personal Protecti ve Equipmen) described below: 



Protectivegloves


Safetyshoes


Workoveralls


STEP OPERATION IMAGE













1 






DISMANTLINGTHEDISC
s Completelyunscrewthehandwheel (1) . 










1 





s Removethewashers (2) and (3) . 
s Applyleveragetothedisc (A) andremoveitfrom
thedriveshaft(B).




1 
3
2

A

B 
05‐HANDLINGANDINSTALLATION
