Cosmo CX 1500 - Verifying Suitability of the Tractor; Calculation of the Front Ballast

TWIN DISC CENTRIFUGAL FERTILIZER SPREADER - FERTI 1500/2150/2400/2800/3200
TWIN DISC CENTRIFUGAL FERTILIZER SPREADER - CX 1500/2150/2400/2800/3200
5-35
Cod. MNenA055CER05 Rev. 05/05.2018 © Agrex S.p.A.



DANGER!
Danger of breakage during operation, tractor stability, steering and braking capacity may be
insufficientintheeventofnon‐compliantuse.

DANGER!
Danger of crushing, cuts, entrapment, entrainmentandcollisionintheeventwheretractor
stability,steeringandbrakingcapacityareinsufficient.

CAUTION!
Seethe tractor’slogbookfortheadmissiblevaluesofoveralltractorweight,axleloadsandthe
tyrecapacity.

5.3. VERIFYINGSUITABILITYOFTHETRACTOR


s Verifythatthe tractorissuitablebeforeattachingorhookingthemachinetothetractor. 
s Test the brakes to makesure that the tractor decelerates as required even when the machine is connected. 
s Specific requirements for tractor suitability: 
‐ admissibleoverallweight 
‐ admissibleaxleloads 
‐ capacityofthetyresfitted. 
Thesedatacanbefoundonthetractor’sratingplate,inthelogbookandinthe”usermanual”. 
s Thetractor’sfrontaxlemustalwayssupportatleast20%ofthetractor’semptyweight. 
s The tractor must achieve the deceleration require d by the manufacture r even when the machine is connected. 



5.3.1. CALCULATIONOFTHEFR ONTBALLAST




HOWTO CALCULATETHE FRONT BALLASTTO BEAPPLIEDTOTHETRACTOR 
(Tractor/FertilizerSpreadersstabilitycalculation)

DuetotheweightoftheFertilizerSpreadersandthematerialcontainedinthehopper,thecombinationoftractorandFertilizerSpreaders
maybecomeunstable. 
To check overall stability of the machine,the following formula canbe applied to determine the minimum front ballast (I
F,min
) to ensure
aweightof20%ofth etractor’semptyweightonthefrontaxle: 




I
F,min
=
(I
R
× (c + d)) - (T
F
× b) + (0,2 × T
E
× b)
(a + b)
05‐HANDLINGANDINSTALLATION
