CONNECTIONS:
3
Cod.3101015

4 
J4
J4
J6
J5
J5
1. “ECSSystem”system 
control interface. 
2. “ECSSystem”interface
connectioncable. 
1
Cod.3101005

5
Cod.3101010

Cod.3101006 
H‐BLOCK 
6 
J1 J2
J1 J2
J3
Cod.3101011
8 
Cod.31 01009
Right
side
Cod.3101009
Left
side
J8 J8 J7 J7
3. Connectioncablefrom 
thebatterypower
connector
(Optional), if the
system is not powered from
the iso 12369 connector.
4. Wiredproximitysensor
forspeeddetection with
phonicwheel. 
Note - Speed can also be
detected by:
GPS device;
Signal from iso 11786
connector
5. Mainwiringconnecting
thesystems.
6. Sensorandactuator
controlmodule. 
7. Actuators.
8. Secondarywiring
connecting the systems. 
7  7 

5.2.14. MANAGEMENTCOMPUTERKIT,modelECSSystem(OPTIONAL)
Iscomposedof: 
- Computer
- Electric actuators
- Actuator electronic card
- Electrical wiring
- Speed wheel sensor
Theflow‐rate(kg/ha)andspreadwidtharesetonthe
managementcomputer,modelECSSystem,which
automaticallycontrolstheopeningoftheshuttersandthe
meteringofproductbasedontractorspeed. 
Readthe
usermanualfortheECSSystemcomputer.






























