DANGER!
Mechanicaldangerduetoraising/loweringthemoveablelimiter,withtherisksofcrushing,cuts,
amputation,entrainment,entrapmentandimpact.
Keepasafedistanceawayfromthemachine.

5.6.7. ADJUSTINGTHEMOBILEFOCUSERFOR CENTRALBOUNDARYSPREADING(optional)


Proceedasfollows:

STEP OPERATION IMAGE






1 

s Hydraulicallylowerthelimiter. 
§“5.2.3.HYDRAULIC CONNECTIONS” on
page5‐11 
s Switchoffthetractor’sengineandremovethe
keysfromtheignition.
s Blockthevehiclecomprisingthetractorandthe
machinetoavoidaccidentalmovementwhen
workingonthemachine.
s Makesureallofthemovingpartsonthemachine
havestopped.








2 

Adjust the limiter according to the fertilizer trajectory: 
s Loosenthehandle (M) . 
s Adjustthelimiteronthespreaderdisc 
s Tightenthehandle (M) . 

Runaspreadingtestswiththelimiteractive,
otherwise repeat the adjustment with the machine off. 
§“5.2.9.MOBILEFOCUSERFORCENTRAL
BOUNDARYSPREADING(Optional)”onpage
5‐29












M 






3 






s Afterspreadingontheedgesofthefield,raisethe
limiterand continuewithnormalspreading.



