TWIN DISC CENTRIFUGAL FERTILIZER SPREADER - CX 1500/2150/2400/2800/3200
4-3
4.
GENERALDESCRIPTION
This section describes the machine with the objective of helping operators understand the general operating principle and get to know
the main parts and components.
4.1.
OPERATION
The CX fertilizer spreaders are intended for use by profes-
sional operators and subcontractors, due to their high
performan- ce in spreading product over extensive areas of land.
The machine comprises 2 spreader discs (replaceable) activated
by the tractor’s PTO, with rotary movement from the inside to the
outside and in the opposite direction to travel, each fitted with 2
different length distributor blades, one short and one long.
At the top of the machine is a feed hopper, featuring of 2 conical
bottom plates with adjustable opening; these feed the product to
be spread onto the spreader discs.
04‐GENERALDESCRIPTION
