TWIN DISC CENTRIFUGAL FERTILIZER SPREADER - FERTI 1500/2150/2400/2800/3200
TWIN DISC CENTRIFUGAL FERTILIZER SPREADER - CX 1500/2150/2400/2800/3200
5-15
Cod. MNenA055CER05 Rev. 05/05.2018 © Agrex S.p.A.



CAUTION
Ifduringoperation,vibrationsorunusualnoisecanbeheardcomingfromthespreaderdiscs,im‐
mediatelystopthemachineandcontactyourlocalservicecentre.

STEP OPERATION IMAGE













2 



ASSEMBLINGTHEDISC
s Cleanandgreasethedriveshaft (B) . 
s Insertthecentreholeofthedisc (A) onthedrive
shaft.
s Pushthediscdownwardsandturnituntilitis
lockedbythepin (C) onthedriveshaft. 




B
C





s Fastenthediscusingthehandwheel (1) andthe
washers (2) and (3) .
s Tightenthehandwheel (1) . 

1 







2 
3 










3 



Fitthespreaderdiscsonthecrossbarsothattheopenpartofthebladesisfacinginthedirection
ofrotationandfertilizerfeed.

05‐HANDLINGANDINSTALLATION
