Cotech FT0203 - Sensor Mounting; Rain gauge mounting; Thermometer;hygrometer mounting

28
ENGLISH
Rain gauge
1. Remove thewater collector from therain gauge.
2. If mounting onto amast, use
thepipe clamp, washer and
nut (M5).
For horizontal or vertical mounting,
use amethod of attachment that is
appropriate for thesurface in question.
3. Replace thewater collector and lock it into place by
twisting it in thedirection indicated by thearrow. Insert
thefilter into thewater collector.
Thermometer/hygrometer
• Place thesensor in alocation that is protected from direct
sunlight and rain.
• Mount thesensor at least 1.5m above theground.
Fasten ascrew to thewall and hang up thesensor using its
hanging hole.
