Cray ClusterStor L300 - Page 114

Loom Label Component Side/Port Switch Port
White LH Side 5 SSU4 A I 100G SW0 10
White LH Side 6 SSU5 A I 100G SW0 12
White LH Side 7 MMU / AMMU A I / I 100G SW0 14
White LH Side 8 SMU A I 100G SW0 16
Blue RH Side 9 SSU0 B I 100G SW1 32
Blue RH Side 10 SSU1 B I 100G SW1 30
Blue RH Side 11 SSU2 B I 100G SW1 28
Blue RH Side 12 SSU3 B I 100G SW1 26
Blue RH Side 13 SSU4 B I 100G SW1 24
Blue RH Side 14 SSU5 B I 100G SW1 22
Blue RH Side 15 MMU / AMMU B I / I 100G SW1 20
Blue RH Side 16 SMU B I 100G SW1 18
Table 24. Lustre 100GbE Data Network Interconnect List - Storage Rack with Optional MMU (Arista 32-port)
Loom Label Component Side/Port Switch Port
White LH Side 1 SSU0 A I 100G SW0 2
White LH Side 2 SSU1 A I 100G SW0 4
White LH Side 3 SSU2 A I 100G SW0 6
White LH Side 4 SSU3 A I 100G SW0 8
White LH Side 5 SSU4 A I 100G SW0 10
White LH Side 6 SSU5 A I 100G SW0 12
White LH Side 7 SSU6 A I 100G SW0 14
White LH Side 8 MMU* A I 100G SW0 16
Blue RH Side 9 SSU0 B I 100G SW1 32
Blue RH Side 10 SSU1 B I 100G SW1 30
Blue RH Side 11 SSU2 B I 100G SW1 28
Blue RH Side 12 SSU3 B I 100G SW1 26
Blue RH Side 13 SSU4 B I 100G SW1 24
Blue RH Side 14 SSU5 B I 100G SW1 22
Blue RH Side 15 SSU6 B I 100G SW1 20
Blue RH Side 16 MMU* B I 100G SW1 18
