Procedure
1. Log into CSSM.
2. Click on the Node Control tab.
3. Stop the Lustre file system.
4. Power off the nodes.
a. Select all nodes to power off.
b. Select Shutdown from the Selected Nodes drop-down menu.
5. After all of the nodes are shut down, physically power off the enclosures -- turn off the power switches (at the
back of the rack).
● The power switches for the 2U24s are on the power and cooling modules (PCMs).
● The power switches for the 5U84 SSUs and ESUs are on the power supplies (PSUs).
16.3 Internal Rack Cabling Reference
Standardized internal rack cabling is determined at the factory using the SCD. The SCD lists all of the internal
cable connections for the system and includes cable label information and each cables source and designation
device.
Labels denote: <U position> <device> <Port>.
Table 5. SCD Cable Routing Tables
# Source Source Destination Destination
1 sw00 u41sw00-p13 u42sw01-p13 sw01
2 smu u36smu-A1 u41sw00-p09 sw00
3 smu u36smu-A2 u42sw01-p09 sw01
4 smu u36smu-B1 u41sw00-p15 sw00
5 smu u36smu-B2 u42sw01-p15 sw01
6 mmu u34mmu-A1 u41sw00-p10 sw00
7 mmu u34mmu-A2 u42sw01-p10 sw01
8 mmu u34mmu-B1 u41sw00-p16 sw00
9 mmu u34mmu-B2 u42sw01-p16 sw01
12 pdu lhs-pdu-eth u41sw00-p12 sw00
13 pdu rhs-pdu-eth u42sw01-p12 sw01
14 lhs u38lhs-service u41sw00-p11 sw00
15 rhs u38rhs-service u42sw01-p11 sw01
Reference
97
