Typical private IP address for SMU controllers, MMU controllers, and SSU OSS nodes, and the IBoIP addresses
are listed in the table.
Table 4. Typical IP Addresses for SMU, MMU, OSS, and IPMI
LMN IB Net IPMI
SMU n000 172.16.2.3 10.10.100.1 172.16.0.101
SMU n001 172.16.2.4 10.10.100.2 172.16.0.102
MMU n002 172.16.2.5 10.10.100.3 172.16.0.103
MMU n003 172.16.2.6 10.10.100.4 172.16.0.104
ssu0 n004 172.16.2.7 10.10.100.5 172.16.0.110
ssu0 n005 172.16.2.8 10.10.100.6 172.16.0.111
ssu1 n006 172.16.2.9 10.10.100.7 172.16.0.112
ssu1 n007 172.16.2.10 10.10.100.8 172.16.0.113
ssu2 n008 172.16.2.11 10.10.100.9 172.16.0.114
ssu2 n009 172.16.2.12 10.10.100.10 172.16.0.115
ssu3 n010 172.16.2.13 10.10.100.11 172.16.0.116
ssu3 n011 172.16.2.14 10.10.100.12 172.16.0.117
ssu4 n012 172.16.2.15 10.10.100.13 172.16.0.118
ssu4 n013 172.16.2.16 10.10.100.14 172.16.0.119
ssu5 n014 172.16.2.17 10.10.100.15 172.16.0.120
ssu5 n015 172.16.2.18 10.10.100.16 172.16.0.121
blank blank Mgmt Net IB Net ipmi
Standardized Rack Configurations
35
