Creality CR-10 Max User Manual

3. Adjust the platform height by turning the knob underneath. Adjust the printing platform and
nozzle to enable the two to just fit each other perfectly with a gap of 0.05mm. Use a piece of A4
paper to assist with the leveling to make sure that the nozzle just scratches on this A4 paper.
4. Adjust all leveling nuts with four corners.
5. Click number ① to test if the platform gap is proper.
6. Repeat abov
e steps once or twice if necessary.
1. Tighten four leveling nuts at the bottom of the platform before
initial leveling.
2. Select “Settings” → “Leveling Mode” → “Assisted Leveling”,
click number ②.
1
2
4
3
5
The nozzle is too far
away from the platform,
so the filament fails to
adhere to the platform.
The nozzle is too close to
the platform, and the
filament is not extruded
insufficiently, and even
the platform is scratched.
Filament is extruded
evenly to adhere to
the platform.
9.Bed Leveling
09

Creality CR-10 Max Specifications

General

Build Volume	450 x 450 x 470 mm
Layer Resolution	0.1 - 0.4 mm
Filament Diameter	1.75 mm
Max Nozzle Temperature	260°C
Connectivity	SD card, USB
Frame Material	Aluminum
File Format	STL, OBJ, AMF
Printing Technology	FDM (Fused Deposition Modeling)
Heated Bed	Yes
Nozzle Diameter	0.4 mm
Supported Materials	PLA, ABS, PETG, TPU
Display	Touchscreen
Print Speed	≤180mm/s, Normal 30-60mm/s
Max Bed Temperature	100°C
Bed Leveling	Automatic
