Creality CR-10 Max User Manual

1. Printing Platform Installation
2. Gantry Frame Installation
3. Gantry Frame Fixation
M4X20 Head Cap Screw 4pcs
M5X45 4pcs
Support Rod 4pcs
M6 x 40 Screw rod 2pcs
Eye Bolt M6 x 26 2pcs
M6 Nut 4pcs
M5 x 12 Screw 8pcs
M5 T-Nut 4pcs
M4 X 8
M4 T-Nut
2pcs
2pcs
M4 x 20 6pcs
T block 2pcs
4. Support Rod
Installation
5. Filament Holder Installation
Hexagon flat round head
4.Device Installtion
04

Creality CR-10 Max Specifications

General

Build Volume	450 x 450 x 470 mm
Layer Resolution	0.1 - 0.4 mm
Filament Diameter	1.75 mm
Max Nozzle Temperature	260°C
Connectivity	SD card, USB
Frame Material	Aluminum
File Format	STL, OBJ, AMF
Printing Technology	FDM (Fused Deposition Modeling)
Heated Bed	Yes
Nozzle Diameter	0.4 mm
Supported Materials	PLA, ABS, PETG, TPU
Display	Touchscreen
Print Speed	≤180mm/s, Normal 30-60mm/s
Max Bed Temperature	100°C
Bed Leveling	Automatic
