X/Z-axis Pulley Adjustment
X-axis
Z-axis
Z-axis
Before switching on the machine, please check the tightness of the pulley by gently toggling it with your hand and check if it is idling
or stuck
(as shown in Figure A).
If yes, please use an open-end spanner to adjust the hexagonal eccentric isolation column to make it rotate smoothly.
6.Adjusting Pulley Tightness
11
Figure A

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Creality CR-M4 and is the answer not in the manual?

Creality CR-M4 Specifications

General IconGeneral
Build Volume450 x 450 x 470 mm
Filament Diameter1.75 mm
Max. Nozzle Temperature300°C
Number of Extruders1
Frame MaterialAluminum Alloy
Printing TechnologyFDM (Fused Deposition Modeling)
Nozzle Diameter0.4 mm
ConnectivityUSB, Wi-Fi
Supported MaterialsPLA, ABS, PETG, TPU
Power Supply50/60Hz
Print Speed30 - 120 mm/s
