Creality CR-M4 - Equipment Introduction

1. Equipment Introduction
1
Z-axis Cable Drag Chain
1
2
2
X-axis Limit Switch
3
Extruder Extrusion Kit
4
4
Printing Platform
5
Y-axis Tensioner
6
USB Flash Drive Port
8
7
7
Type-c port
13
14
8
Material rack
9
Filament Detection
5
6
10
X-axis Cable Drag Chain
10
9
11
X-axis Tensioner
18
19
20
15
16
17
12
Display screen
3
13
Y-axis Motor
14
Pull Rod
15
X-axis Motor
16
Power Switch
17
Z-axis Motor
18
19
20
Y-axis Limit Switch
01
RJ45 Network Interface
Camera Interface
11
12
