Crestron CP3N Reference Guide

Reference Guide – DOC. 7150B 3-Series Control Systems • 11
Add Local User
To add a local user to the control system, issue the ADDUSER command.
• Syntax: ADDUSER -N:username -P:password
o -N: Specifies the name of the local user that will be created
o -L: Specifies a password for the local user
• Example: ADDUSER -N:jsmith -p:user01
A local user is created without any access rights. To assign access rights to a local
user, the user must be added to at least one local group. For more information,
refer to "Add User to Group" on page 13.
Delete Local User
To remove a local user from the control system, issue the DELETEUSER username
command.
When a local user is removed, the user is also removed from any local groups.
Add Local Group
To add a local group to the control system, issue the ADDGROUP command.
• Syntax: ADDGROUP -N:groupname -L:accesslevel
o -N: Specifies the name of the local group that will be created
o -L: Specifies the access level for the local group
 A: Administrator
 P: Programmer
 O: Operator
 U: User
 C: Connection only
• Example: ADDGROUP -N:CresProgs -L:P
NOTE: A predefined access level must be assigned to a group when it is created.
When a user is added to a group, the user inherits the access level set for the
group. Certain control system functions and console commands are accessible
only to users with corresponding access levels.
If a user belongs to multiple groups, the user's access level is the combined
access level of all groups that contain the user.

Crestron CP3N Specifications

General

Internal memory	0.5 GB
Storage media type	Flash
Internal memory type	SDRAM
Internal storage capacity	4 GB
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	24 W
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Product color	Black
Heat dissipation	50 BTU/h
Housing material	Metal
Ethernet LAN (RJ-45) ports	2

Weight and Dimensions

Depth	167 mm
Width	439 mm
Height	44 mm
Weight	1420 g
