Crestron CP3N Reference Guide

Reference Guide – DOC. 7150B 3-Series Control Systems • 33
Control Subnet
The AV3, PRO3, and CP3N have a dedicated Control Subnet, which allows for
dedicated communication between the control system and Crestron Ethernet
devices without interference from other network traffic on the LAN.
When using the Control Subnet, observe the following:
CAUTION: Do not connect the CONTROL SUBNET port to the LAN. The
CONTROL SUBNET port must only be connected to Crestron Ethernet devices.
• The control system acts as a DHCP server to all devices connected to the
Control Subnet and assigns IP addresses as needed.
• A DNS server is built in to the control system to resolve host names.
• Only connect Crestron Ethernet devices to the Control Subnet.
The control system can also operate in isolation mode by issuing the
isolatenetworks ON command.
• Devices on the Control Subnet do not have any resources on the LAN side.
For example, if a touch screen with a SmartObjects® technology object
requiring network access is installed on the Control Subnet operating in
isolation mode, the object will not work.
• Devices on the LAN do not have access to any devices on the Control
Subnet. Crestron Toolbox also does not have access to these devices
when it is connected to the LAN. To configure devices on the Control
Subnet with Crestron Toolbox (outside of runtime), the computer running
Crestron Toolbox must be connected to the Control Subnet.
• Any NAT/port mapping rules that were previously created do not work
when the control system is in isolation mode.
NOTE: If the control system is running in isolation mode, Crestron Ethernet
devices requiring Internet access should not be connected to the CONTROL
SUBNET port (directly or indirectly) and should be instead connected to the LAN.

Crestron CP3N Specifications

General

Internal memory	0.5 GB
Storage media type	Flash
Internal memory type	SDRAM
Internal storage capacity	4 GB
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	24 W
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Product color	Black
Heat dissipation	50 BTU/h
Housing material	Metal
Ethernet LAN (RJ-45) ports	2

Weight and Dimensions

Depth	167 mm
Width	439 mm
Height	44 mm
Weight	1420 g
