Crestron CP3N Reference Guide

6 • 3-Series Control Systems Reference Guide – DOC. 7150B
Establish Communications
The control system must establish communications with a computer in order to
upload programs, troubleshoot, or perform diagnostics.
Depending on the control system capabilities, the following communication
protocols may be used to connect with a 3-Series control system:
• USB communication with a PC via the COMPUTER port on the control
system (requires Crestron Toolbox software)
• Ethernet communication via SSH or SSL/TLS
USB Connection
To connect to the control system via USB:
1. Connect the COMPUTER USB port of the control system to the USB port
of a computer with a USB A to B cable.
2. Open Crestron Toolbox software.
3. Click the pencil icon at the bottom left of any tool in Crestron Toolbox.
A dialog box for editing the connection type is displayed.
4. Click the USB radio button.
Connection Type Dialog Box - USB

Crestron CP3N Specifications

General

Internal memory	0.5 GB
Storage media type	Flash
Internal memory type	SDRAM
Internal storage capacity	4 GB
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	24 W
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Product color	Black
Heat dissipation	50 BTU/h
Housing material	Metal
Ethernet LAN (RJ-45) ports	2

Weight and Dimensions

Depth	167 mm
Width	439 mm
Height	44 mm
Weight	1420 g
