Crestron CP3N Reference Guide

58 • 3-Series Control Systems Reference Guide – DOC. 7150B
Connect to Crestron XiO Cloud Service
The Crestron XiO Cloud service allows all supported Crestron devices across an
enterprise to be managed and configured from one central, secure location in the
cloud. The Crestron XiO Cloud service may be used to view the status of a device,
to configure various device and network settings, to manage licenses, and to
update device firmware.
Devices must be claimed by the Crestron XiO Cloud service before they may be
managed by the service. Devices may be claimed individually or as a group.
For information on creating environments, managing devices, and managing
users with the Crestron XiO Cloud service, refer to the Crestron XiO Cloud User
Guide (Doc. 8214).
Claim a Single Device
To claim a single device:
1. Record the MAC address and serial number of the device. The MAC
address and serial number are labeled on the shipping box or on a sticker
attached to the device.
NOTE: Use the MAC address labeled MAC Address .
2. In the Crestron XiO Cloud service, click the ENVIRONMENT menu button
to display a drop-down menu.
Environment - Drop-Down Menu
3. Click Claim Device. The Claim Device dialog box is displayed.

Crestron CP3N Specifications

General

Internal memory	0.5 GB
Storage media type	Flash
Internal memory type	SDRAM
Internal storage capacity	4 GB
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	24 W
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Product color	Black
Heat dissipation	50 BTU/h
Housing material	Metal
Ethernet LAN (RJ-45) ports	2

Weight and Dimensions

Depth	167 mm
Width	439 mm
Height	44 mm
Weight	1420 g
