Reference Guide – DOC. 7150B 3-Series Control Systems • 39
Remove Peer Entry
To remove a peer (slave) entry from the IP table, use the REMPEER command.
• Syntax: REMPEER cipid ip_address/name [-D:device_id] [-
C:cipport] [-P:program][-U:RoomId]
o cipid: The ID of the CIP node (in hexadecimal format)
o ip_address/name: The IP address (in dot decimal notation) or the
name of the site for DNS lookup
o -D:device_id: The device ID in the device redirection table (in hex,
must be less than 256)
o -C:cipport: The CIP port number for the connection (must be
greater than 256)
o -P:program: The program number on the control system that uses
the device (default is 1)
o -U:RoomId: The room ID used for communication with a Crestron
Virutal Control server (max length is 32 characters, valid values are A-
Z and 0-9)
• Example: REMPEER 13 255.255.255.255 -D:134 -C:458 -P:3
-U:AVF469
Load IP Table
To load a program-specific DIP file from removable media to the "\Sys\"
directory of the control system, issue the LOADIPTABLE command.
• Syntax: LOADIPTABLE -p:[AppId] [path]
o -p:[AppId]: The specific program identifier
o path: The path of the file on removable media, including "\" (such as
"\RM\TmpDir" or "\RM2\dipDir"
• Example: LOADIPTABLE -p:1 \RM\dipDir
NOTE: The program must be restarted for the new IP table to take effect.

Crestron CP3N Specifications

General

Internal memory	0.5 GB
Storage media type	Flash
Internal memory type	SDRAM
Internal storage capacity	4 GB
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	24 W
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Product color	Black
Heat dissipation	50 BTU/h
Housing material	Metal
Ethernet LAN (RJ-45) ports	2

Weight and Dimensions

Depth	167 mm
Width	439 mm
Height	44 mm
Weight	1420 g
