APPENDIX 4
Specification
Models CS2300-R Stand Alone
CS2301 Plug-on (CS2300-R + CS2325)
Dimensions (h x w x d) 95 x 125 x 25 mm
Weight 250 grams
Temperature -20C to +60C transit, -10C to +50C operating
Humidity 0 - 80% non-condensing
Mounting Any orientation
Warranty 5 years
Power Requirement 9.0 - 30.0volts DC, 0.1volt max ripple
Current Consumption 30mA quiescent at 12 volt supply
15mA quiescent at 24 volt supply
100mA operating
LAN(IP) Card 20mA operating
Plug-on Accessories Supply must not exceed +15 volts when
CS2325, CS2351 or CS2355 are used.
Radio Path GPRS & Data service on a GSM network
Aerial 50 ohm (nominal) on MMCX socket
LAN(IP) Path 10/100 Base-T port on RJ45 socket
TCP/IP and UDP
Telephone Path PSTN technology. CTR21 approved.
Expansion 9 to 12 inputs on CS2351, CS5351 & CS5355
LAN connection using CS5355
Plug-on (Control Panel) using CS2325
Low Battery 10.8-11.0 volts falling, 11.8-12.0v recovery
Outputs 2 ‘normally open’ relays (60v 100mA contacts)
Input Terminals Max +30 volt, Min 0 volts DC (reference
Supply 0v terminal), 100K pulldown to 0v.
User Servicable There are no user servicable parts within
Parts the DualCom.
66
