Chapter 2. Configuration
2-4
Step 5: Install the SHDSL Router
Caution: To avoid possible damage to this Router, do not turn on the router
before Hardware Installation.
? Connect the power adapter to the port labeled DC-IN on the rear panel
of the product.
? Connect the Ethernet cable.
?If the 1-port router is directly connected to PC or NB, the Ethernet cable
must use a cross over cable. If the 1-port router is connected to hub or
switch, be sure that the hub or switch supports auto-sensing. If the HUB
or Switch supports auto-MDIX, then both cross over and non cross over
Ethernet cables are suitable. Otherwise, only straight through Ethernet
cables may be used. The 4-port router has its own auto-MDIX switching
hub so both straight through and cross-over Ethernet cables may be used.
? Connect the phone cable to the SHDTU03 and the other side of phone
cable to wall jack.
? Connect the power adapter to power source.
? Turn on the PC or NB which is used for configuration of the Router.
