Chapter 3. Set-Up
3-7
3.2 Advanced Set-Up
Advanced setup contains the configuration steps for SHDSL, WAN,
Bridge, Route, NAT/DMZ, Virtual server and firewall parameters.
SHDSL
You can setup the Annex type, data rate and SNR margin for SHDSL
parameters in SHDSL.
Click SHDSL
Annex Type: There are two Annex types
supported, Annex A and Annex B, in
SHDSL.
Data Rate: you can setup the SHDSL data
rate in multiples of 64kbps.
SHDSL SNR margin: the margin range is
from 0 to 10.
?: Generally, the SNR margin does not
require changing because it will affect the data rate.
The screen will prompt with the parameters that will be written to Flash. Check the parameters
before writing to Flash. Press Restart to restart the router with the new configuration or press
continue to setup other parameters.
