Chapter 8. Configuration Commands
8-21
PAT
To configure Port Address Translation, move the cursor “>>” to the pat command and press
enter.
>>
clear Clear virtual server mapping
modify Modify virtual server mapping
list Show virtual server mapping pool
You can delete virtual server mapping entries- from 1 to 10- by using the clear command.
You can create up to 10 virtual server mapping entries via the modify command.
----------------------------------------------------------------------
Command: setup ip_share pat modify <1~10>
Message: Please input the following information.
Virtual server entry number <1~10>: 1
----------------------------------------------------------------------
After keying in enter, the screen will prompt as below.
>>
interface Active interface
port TCP/UDP port number
server Host IP address and port number
protocol Transport protocol
name Service name
begin The schedule of beginning time
end The schedule of ending time
Set the active interface number via the interface command.
You can configure the global port number by using the port command.
The local server, host, IP address and port number are configured via the server command.
The authorized access protocol is setup via the protocol command.
The Name command can be used to configure the service name of the host server.
Begin and end commands are used to setup the local server schedule to access.
You can view the fixed NAT mapping entries via the list command.
