Cub Cadet 900 series Professional Shop Manual

310-0510 IHT
31
No. DESCRIPTION No. DESCRIPTION
1 Main Housing, Assembly, Black
Main Housing, Black
Bushing .865 x .985 x .790
2 Side Housing, Assembly, Black
Side Housing, Black
Bushing .865 x .985 x .790
Bushing .624 x .719 x .562
3 Center Section Assembly
Center Section Machined
Bushing .707 x .788 x .591
4 Swashplate, Trunnion Machined
5 Block - Assembly
Block - Cylinder
Piston
Spring Compression
Thrust - Washer
6 Sealant
7 Hex Flange Screw 1/4-20 x 1.25
9 Shaft, Input
10 Ring - Retaining
11 Washer, Flat 1.23 x 1.57 x .04
12 Ring - Retaining
13 Seal, Lip 17 x 40 x 7
14 Ball Bearing 17MM x 40MM x 12MM
16 Hex Flange Head Screw 5/16-24 x 0.94 w/patch
17 Lip Seal 18 X 32 X 7
18 Arm, Control
19 Bearing, 30X52X13 Thrust
23 Check Plug Assembly, .027, Washer, “A” Port
24 Shaft, Motor
27 Gear - Pinion, 13T
28 10T/48T Gear
29 Gear, 10T Jackshaft
30 60T Bull Gear
31 Sleeve Bushing (Inboard)
32 Sleeve Bushing (Outboard) 1.002 x 1.571 x .625
33 Washer, Flat .77 x 1.5 x .10
34 Lip Seal Axle Seal
35 Shaft, Black, Axle 1.00/.75 x 10.65 (Flange, R.H.)
36 Shaft, Black, Axle 1.00/.75 x 16.25 (Flange, R.H.)
37 Miter Gear, 12T (Splined)
38 Miter Gear 12T (0.5 ID)
39 Shaft
40 Ring, Spiral Retaining
41 Pin, Jackshaft
42 Magnet, Ring
43 Spring, Bypass
44 Bolt, Hex Flange 3/8-24 x 2.5
45 Filter
46 Base, Filter
47 Actuator, Bypass
48 Rod, Bypass Actuator
49 Arm, Bypass
50 Retaining Ring .250 External
51 Seal, Lip ..250 x .750 x .250 TC
52 Flat Washer, .63 x 1.0 x .05
53 Retaining Ring
55 Spring, Block
56 Washer, Thrust .59 x .79 x .04
57 20W-50 Oil
58 Brake Yoke Kit
59 Disk, Brake
60 Brake Puck
61 Puck Plate
62 Brake Actuating Pin
63 Bolt, Hex Head 1/4-20 x 2 w/patch
65 Spacer
66 Spring, Brake Arm Bias
68 Arm, Brake
69 Nut, Castle 5/16-24
70 Cotter Pin 3/32 X 3/4
71 Compression Spring Brake Anti-Drag
72 Washer, Flat .51 x 1.00 x .03
73 Washer, Flat .34 x .88 x .06
74 Oil Seal .625 X 1.0 X .25
75 Check Plug Assy, .027, Washer, “B” Port
94 Ball Bearing .62 I.D. x 1.38 x .44
95 Socket Head Cap Screw, 5/16-24 x 1-1/2
96 Spacer Locating
97 Screw, Countersunk 5/16-18 x 1.0
98 Arm, Return
99 Puck, Adjusting
100 Washer, .32 x 1.60 x .24
101 Spring, Extension
102 Spacer, .260 x .560 x .87
103 Bracket, Torque
107 Deflector
108 Washer, Motor Shaft .71 x 1.16 x .04
109 Plug, 9/16-18 (Metal)
110 Torx Head Screw 5/16-18 x 1.5
114 Spring Guide
117 Pin, Spring .304 x.75
119 Fan, 7.0 in. (10 Blade)
120 Pulley, 3.86 in.
121 Nut, Hex Lock 1/2-20 w/nylon insert
122 Washer, OD slotted .53 x 1.63 x .06
124 Center Section-Filter-Bypass Assy
Center Section Machined
Base Filter
Check Plug Assy.
Spring, Bypass
Actuator, Bypass
Deflector
Filter
Bushing, .707 X .788 X .591
125 Filter Assembly
126 Kit, Fan/Pulley
127 Kit, Seal & O-Ring
Seal, Lip 17 x 40 x 7
Seal, Lip 18 x 32 x 7
Seal, Lip 1.00 X 1.577 X .250
Seal, Lip .250 X .750 X .250
Seal, Lip .625 X 1.0 X .25
O-Ring .299 x .505 x .103
135 Assembly, Block 7 Piston
Block, Cylinder
Piston
Spring, Compression
Seat
152 Nut, Hex Lock 3/4-16
153 Assembly, Hub
Hub, 4 Stud Metric (Painted)
Stud, M12 x 1.5 (Rib Neck)
164 Plug, 9/16-18 (Magnetic)
165 Fitting, 90° 9/16 SAE Beaded
200 Kit, 60T Bull Gear Diff Pins
Gear, 60T
Pin, 0.5 OD
Bulletin, Bull Gear
310-0710 ITEMS LIST
