Cub Cadet 900 series Professional Shop Manual

CVT Drive and brake system
91
35g. Re-hook the brake spring to the brake arm
36. Re-install the shift rod pillow block.
37. Give the transaxle a final spin-test before instal-
lation.
Table 1:
Specification U.S. Metric
Pinion end play .010”-.015” .25-.38mm
Pinion run-out .002”-.010” .05-.25mm
Pinion back-lash .006”-.014” .15-.36mm
Differential rivet.-to-
gear clearance
.030”
minimum
.762mm
Axle end-play .010”-.08” .25-2.0
Amount of Durina
g r e a s e , 1 0 o z . t u b e
(P/N: 737-0148) 2X
20 fl.oz 0.59 liters
Brake clearance .010”-.015” .25-.38mm
Table 2: Drive System Torque Specs.
Fastener Torque in-lb. Torque N-m
Seat bolt 60-80 17-20
Lug nut 350-500 41-57
Wheel bolt 160-190 18-22
Crankshaft bolt 450-600 51-68
Tq. bracket bolt 175-250 20-28
Axle T-bolt nuts 150-180 17-20
Tensioner bracket 150-180 17-20
Pedal shaft straps 150-180 17-20
Belt keeper nut /bolt 150-180 17-20
Idler pulley bolt 150-180 17-20
Brake yoke bolts 90-135 10-15
Input pulley nut 300-400 34-45
Housing screws 90-135 10-15
Detent screw 160-200 18-23
V.S. pulley bolt 150-180 17-20
V.S. bearing cover 90-135 10-15
Make-up pulley pivot
bolt
175-250 20-28

Cub Cadet 900 series Specifications

General

Transmission	Hydrostatic
Steering	Power steering
Turning Radius	18 inches
Engine	Kohler
Drive	2WD
Warranty	3 years
