Cub Cadet SC2450 - HST Pressure Release Lever and Reverse Override Switch

5-8
5. NAMES AND FUNCTIONS OF COMPONENTS
Sc2450 Operator's Manual
(16)Reverse-override-switch
Normally, reversing the tractor stops the Mid-Power
Take Off (PTO) and the Rear Power Take Off (PTO).
To drive the Power Take Off (PTO) while reversing
the tractor, use the reverse-override-switch.
(A) Reverse-override-switch
(17)Power Take Off (PTO) switch
This switch is used to rotate the Power Take Off
(PTO).
(A) Power Take Off (PTO) switch
(a) Turn off: Push the switch.
(b) Turn on: Pull the switch.
(18)Range gear lever
Use the range gear lever to select the speed that
best suits the intended operation.
(A) Range gear lever
(a) SLOW : Used for heavy-load operation.
Low traveling speed.
(b) FAST : Used for light-load operation.
High traveling speed.
3014919d
(A)
3014919g
(A)
(a) (b)
3014926
3014919a
(A)
(a)
(b)
