3.12. The Cable Holder
To fix cables connected to the connector on a rear side of the Assistant or Assistant-S a cable holder
is used. The cable holder fixed to the rear of the Assistant by screws.
Cable Fixation
INE IR-REC S9 / CU Ering
IR 1 IR 2
IR 3 IR 4
S 5 S 6
S 7 S 8
A 1 A 2
A 3 A 4
IO 1 IO 2 IO 3 IO 4
IO 5 IO 6 IO 7 IO 8
E OUT RS -485 G CONSOLLE AUX 9 AUX 10 AUX 11 AUX 12 AUX 13 AUX 14 AUX 15 AUX 16
AUX 17 AUX 18 AUX 19 AU X 20 AUX 21 AUX 22 AUX 23 AUX 24 OPTION
OPTION
1 432 1 32
1 2
Cable Holder
Mounting Screws
