Chapter 1: Introduction
Use of the system in a manner not specified by these instructions may impair the safety protection
provided by the system. Do not operate the system outside its rated supply voltages or environmen-
tal range
Omission to read the installation and user manuals or to comply with the warnings and references
contained herein can result in serious bodily injury or damages to the controllers
Do not insert metal objects into the connectors
Use the system only as specified, or the protection supplied by the product can be compromised
Follow all installation and maintenance recommendations and consider all provided information
regarding product specifications and limitations
Do not use the system if it does not operate correctly
The enclosures must be closed and locked at all times, particularly when operating the system
Use only specified replacement parts
Inspecting Your Received System
Inspecting your system and making sure you have received all expected parts helps avoid many hassles.
Shipment Contents
Table 1-3 Complete Enclosure Without Modules
Item
Contents
EDGE 2 MAIN CONTROLLER One EDGE 2 Main Controller, One quick start guide
EDGE 2 REMOTE DISPLAY One EDGE 2 Remote Display, One quick start guide
EDGE 2 SCREENLESS CONTROLLER One EDGE 2 Screenless Controller, One quick start guide
EDGE 6-SLOT EXPANSION BOX WITH
HEATSINK PRO
One user and installation manual; One 6-Slot Expansion Box with
an external Heatsink
EDGE 6-SLOT EXPANSION BOX PRO One 6-Slot Expansion Box without an external Heatsink; One user
and installation manual
EDGE 3-SLOT EXPANSION BOX WITH
HEATSINK PRO
One 3-Slot Expansion Box with an external Heatsink; One user and
installation manual
EDGE 3-SLOT EXPANSION BOX PRO One 3-Slot Expansion Box without an external Heatsink; One user
and installation manual
Table 1-4 Modules for 3-Slot Expansion Box and 6-Slot Expansion Box
Item
Contents
EDGE 8IN-4V-6REL FAILSAFE WITH
PLUGIN RELAY PRO
One Failsafe with plug-in relays and its plastic support
EDGE 8IN-4V-6REL FAILSAFE PRO One Failsafe and its plastic support
EDGE 16IN-6REL WITH PLUGIN RELAY
PRO
One 16 inputs, 6 relays with plug-in relays and its plastic support
EDGE 16IN-6REL PRO One 16 inputs, 6 relays and its plastic support
EDGE 4IN-8REL WITH PLUGIN RELAY
PRO
One 4 inputs, 8 relays with plug-in relays and its plastic support
EDGE 4IN-8REL PRO One 4 inputs, 8 relays and its plastic support
18
890–00687 EDGE 2
