Chapter 1: Introduction
Table 1-4 Modules for 3-Slot Expansion Box and 6-Slot Expansion Box (cont'd.)
Item
Contents
EDGE 2 VARIABLE OUTPUT KIT One kit to control two variables
EDGE 1 VARIABLE OUTPUT KIT One kit to control one variable
EDGE 4IN-12V One 4 inputs, 12 outputs for Variable Outputs or 0-10V devices and
its plastic support
EDGE 4IN-8REL FAILSAFE W/PLUGIN
RELAY PRO
One 4 inputs, 8 relays with plug-in relays and its plastic support
EDGE 4IN-8REL FAILSAFE PRO One 4 inputs, 8 relays and its plastic support
EDGE 4IN-6R-2LD
4 analog inputs, 6 relay outputs normally opened, and 2 independ-
ent light dimmer outputs
EDGE 4IN-6R-2LD FAILSAFE 4 analog inputs, 6 relays with two different outputs: normally
opened and normally closed, and 2 independent light dimmer
outputs
Table 1-5 External Module
EDGE 4IN-2V-8DO One 4 inputs, 2 outputs for Variable Outputs or 0-10V devices, 8 dis-
crete outputs to control relays coils or contactors coils, 8 current
sensors inputs to read the relays or the contactors contacts at the
loads side, and its plastic support
Damage Inspection
Your system and its components were carefully inspected both electrically and mechanically before ship-
ment. After unpacking all items, check for any obvious signs of physical damage that may have occurred
during transit. Report any damage to the shipping agent immediately. Save the original box for possible
future shipment.
Returning the Unit for Repair
If you must return the system for repair, carefully package the system in its original box or an equivalent.
Contact your local customer service department to get return instructions. Have on hand the system’s
serial number and date code found on the system’s main board. See Contact Information/Support in this
manual.
Ordering Information
Basic System
A minimum redundant basic EDGE 2 System consists of the following equipment:
• 1 x EDGE 2 Main Controller (Master)
• 1 x EDGE 2 Main Controller (Redundant) or EDGE 2 Screenless Controller (Redundant)
• 2 x EDGE Expansion Boxes or 1 x Expansion Box and 1 x External Power Supply of 150W on
Safety Network
The following external modules can be connected to a basic EDGE 2 System to add more functionality:
• EDGE RS485 Repeater
• EDGE Bin Scale
