6 Installation Order Overview
Topics Covered in this Chapter
▪ EDGE 2 System Installation Order
▪ EDGE 2 System Configuration
▪ EDGE 2 System Operation Summary
EDGE 2 System Installation Order
Physical Installation
Install the EDGE system on the wall according to the plan by respecting the cable distances between con-
trollers, their minimum clearances, and other restrictions:
• EDGE Expansion Boxes and equipment
• EDGE External Modules (EDGE Bird Scales, EDGE Bin Scales, EDGE RS485 Repeater, EDGE
Power Modules, EDGE Weather Station) and equipment
• VR-50\250
• EDGE 2 Main Controller
• EDGE 2 Redundancy Controller
• EDGE 2 Remote Display
• Installation of Ethernet cabling
Module Detection
After turning ON the EDGE 2 system, the EDGE will detect the modules on EDGE Network.
NOTE: The EDGE has to upgrade the modules firmware during module detection. This operation can
take a few minutes. DO NOT CONFIGURE CONTROLLERS UNTIL THE FIRMWARE UPDATES
ARE COMPLETE.
Ethernet EDGE 2 Controller Configuration
Set your Ethernet link if redundancy scheme is used and/or remote control is required: by Ethernet cables
(LAN) or by Ethernet WIFI (WLAN).
Software Update (optional)
You can check to make sure if a software update is available, by going to System->Software Update.
EDGE 2 System Configuration
Configuration
The easiest way is to export an existing configuration from an EDGE 2 or EDGE 1 system and import it to
the new EDGE 2 system.
890–00687 EDGE 2
85
