Chapter 6: Installation Order Overview
NOTE:
Light programs and multiple day schedules will not be exported in the configuration file. Other
ways to create the configuration are by using the WEB browser or by user interface on site.
Minimum configurations needed to operate the EDGE system:
• Site Configuration
• Time and units
• User Management
• Rooms
• Site Name
• Controller Name
• Equipment configuration
• Room Setup
EDGE 2 System Operation Summary
Normal Mode
EDGE system automatically controls the equipment according to their settings and the input feedback or
according to a scenario in the automatic mode. The EDGE system can also control the equipment in
manual mode.
Backup Mode
Modules enter into Backup Mode when no communication is received from either the master controller or
the redundant controller for 2 minutes. Modules do not communicate with each other in Backup Mode.
Backup Mode is a degraded thermostatic control derived from the controller’s configuration.
Temperature controlled equipment uses an average of the assigned temperature probes on the module.
Temperature driven equipment default to Failsafe when its module does not have a temperature probe.
Equipment in bypass are kept in their bypass state in Backup Mode.
Failsafe Mode
Modules enter into Failsafe Mode when powered down.
