Chapter 5: Expansion Box and Virtual Expansion Box Installation
NOTICE
The terminal ground (GND from 24VDC, Green color on diagram block) must be
connected between the EDGE 2 Controller and the EDGE Expansion Box
NOTICE
When there is only communication between Boxes, the terminal ground (GND
from 24VDC, Green color on diagram block) must be connected.
Connecting an Analog Input
A variety of different sensors can be hooked up to the system to monitor various inputs. Analog inputs
can be set in 0-5V mode, in dry contact mode, in 4-20mA mode, and in temperature mode. Some
890–00687 EDGE 2
