Chapter 4: EDGE 2 Controller Installation
NOTICE
The EDGE 2 Remote Display needs an EDGE 2 Main Controller to control the EDGE
system indirectly. An EDGE network without a Main Controller is impossible.
Preparing the Enclosures for Installation
Preparing the equipment before mounting it to the wall ensures all parts are ready to be installed.
Wires are separated into two groups: low voltage and high voltage.
NOTE: The use of rigid conduits up to 1 inch (25.4 mm) is allowed for the EDGE 2 Controllers and the
EDGE PSU 24V 36W.
IMPORTANT: Leave the rated clearance to allow the cover to be removed for maintenance.
Remember
Do not mount the enclosures to drywall only. A structure behind the drywall must be able to support the
enclosures. If needed,add a wooden or metal frame for support.
Preparing the EDGE 2 Controller
1. Open the enclosure by unlocking the latch.
2. Drill a hole the size of your cable connectors or your rigid conduits through the bottom side of the
enclosure.
3. Remove any plastic fragments from the enclosure.
4. Install the cable connector or rigid conduit adaptors to the bottom of the enclosure.
5. Close the enclosures and lock the latch.
If using a Cellular based network, drill a hole the size of the cable connectors or your rigid conduits
through the bottom side of the enclosure.
NOTE: Only EDGE 2 Main Controller and EDGE 2 Controller Screenless could use an external cellular
base.
Preparing the EDGE PSU 24V 36W
1. Unscrew the screws from the cover and remove the cover.
2. Drill a hole the size of the your cable connectors or your rigid conduits through the bottom side of the
enclosure.
3. Remove any plastic fragments from the enclosure.
4. Install the cable connector or rigid conduit adaptors to the bottom of the enclosure.
5. Install the enclosure cover and secure with screws.
Mounting the Enclosures
Securely mounting the enclosures to the wall in the ideal location allows for an optimal use of the system
when navigating the menus.
Before You Begin
