Chapter 5: Expansion Box and Virtual Expansion Box Installation
IMPORTANT: High voltage wires must not passed through plastic support aeration holes.
Figure 5-1 EDGE 3-Slot Expansion Box
Figure 5-2 EDGE 6-Slot Expansion Box
1. Close the enclosures and lock the latch.
2. Drill a hole the size of the your cable connectors or your rigid conduits at the bottom of enclosure.
60
890–00687 EDGE 2
To Next Page
