Chapter 5: Expansion Box and Virtual Expansion Box Installation
WARNING
Take care to not damage the thermal pad when placing the EDGE Variable
Output on the heatsink.
WARNING
Take care to not contaminate the thermal pad when positioning the EDGE
Variable Output on the heatsink.
4. After placing the EDGE Variable Output on the heatsink, screw the screws with a Philip screw driv-
ers with the tightening torque at 15.9lbf*in (1.8N*m).
5. Connect the low voltage control cable provided with your kit from the EDGE Variable Output to the
Expansion card module.
