Cumberland Evolution 4000 - Connecting the Powertrak Power Auxiliary Switches to Evolution 4000

Part No. 4801-5338 Rev 2-2015 Evolution 4000 67 of 86
9.14 Connecting the PowerTrak Power Auxiliary Switches to Evolution 4000
PowerTrak
AUX
SWITCH
CONTROLLER
AC IN
HOT
NEUT.
LOWER
GND.
HOT
OUT
CLOSE
IN
OPEN
IN
COM
UPPER
NOTES:
1. If curtain is setup to pull curtain up to open, then reverse wires connected to“Upper” and
“Lower” terminals.
2. If using Natural Ventilation, DI2 & DI3 become Auxiliary Inputs for NV#3 and NV#4.
Inset A
Tunnel Auxiliary
Input
See Note
below
Inset C
Inset C
Inset B
Vent Auxiliary
Input
NOTE: Vent auxiliary
connects the same as
tunnel auxiliary.
WARNING!
LOW VOLTAGE!
Keep Separate From
High Voltage Wires!
Inset B
PCB 194
Inset A
Open
Close
COM
Open
Close
COM
