Curtis 1310 User Manual

INPUT/OUTPUT SIGNAL SPECIFICATIONS
The input/output signals wired to the J1 through J4 connectors can be grouped by type as
follows; their electrical characteristics are discussed below.
• Digital inputs
• Digital outputs
• Analog inputs
• Analog outputs
• Power
• Communications ports
Digital Inputs
These signal lines can be used as digital (ON/OFF ) inputs. Normally, the ON signal is made by
a connection direct to B+ and OFF is direct to B-. Inputs 1 through 18 will pull low (OFF) if no
connection is made. Inputs 19 through 26 will pull high (ON) if no connection is made.
Inputs 1 through 18 are associated with driver outputs. Inputs 19 through 26 are low voltage
“TTL” level inputs and can be used when connecting to other low voltage (5v) logic circuits or
sensors. The encoder channels are normally used for pulse count inputs from quadrature (2
channel) encoders, but they may also be used as 5v logic level digital inputs. Take careful note
of their much lower voltage range.
DIGITAL INPUT SPECIFICATIONS
SIGNAL NAME PIN
Logic
Thresholds
Input
Impedance
Voltage
Range
ESD
Tolerance
Input/Output 1-16 J1-1
thru
22
24-48V models:
Low = 7.5v
High = 15.8v
48-96V models:
Low = 14.1v
High = 29.7v
24-48V models:
about 5.4 kΩ
48-96V models:
about 22kΩ
*see note below
24-48V models:
-0.5 to 64v
48-96V models:
-0.5 to 124v
± 8 kV
(air discharge)
Input 17-18 J1-17
thru
18
24-48V models:
Low = 7.5v
High = 15.8v
48-96V models:
Low = 14.1v
High = 29.7v
24-48V models:
about 5.4 kΩ
48-96V models:
about 22kΩ
24-48V models:
-0.5 to 64v
48-96V models:
-0.5 to 124v
± 8 kV
(air discharge)
Input 19-22 J1-19
thru
22
All models
High = 3.8v
Low = 1.8v
All models
about 4.5kΩ
24-48V models:
-0.5 to 64v
48-96V models:
-0.5 to 124v
± 8 kV
(air discharge)
Encoder Inputs
Inputs 23-26
J4-1
thru
4
Rising edge
= 3.0v
Falling Edge
= 2.0v
All models
about 4.7kΩ
All models
-0.5 to 5.5 v
± 8 kV
(air discharge)
Tolerance of above values; ±5%
* Outputs 14 and 15 on Model 1310-5210 have over 200kΩ output impedance
1310 Vehicle Control System Users Manual Release Rev B Page 16 of 51
