INSTALLATION AND WIRING
MOUNTING THE CONTROLLER
The Curtis 1310 mounts securely to the vehicle or system using 4 #8 or M4 screws. Care should
be taken to prevent water from splashing or resting on the connector area. If possible, the
connector area should be mounted downward and guarded from water and dust born
contaminants which can degrade the electrical connections.
Fig 2. Controller Mounting
1310 Vehicle Control System Users Manual Release Rev B Page 5 of 51
