VCL RUNTIME RATES
VCL is an interpreted language. Each line of VCL code is converted into an array of pseudo-code
by the WINCL complier which can then be flash loaded into the controller. The controller
interprets these pseudo-codes one line at a time while the system is running (powered). The
table below lists the rate that the VCL interpreter runs each of the various functions (Service
Rate) and lists how many of each function is available to the VCL software (Instances):
FUNCTION FUNCTION FULL NAME INSTANCES SERVICE RATE
ABS Absolute Value 2 4 ms
ADC Analog to Digital Converter Input 2 1 ms
CAN CAN Communications 2 4 ms
CPY Copy 8 4 ms
DAC Digital to Analog Converter Output 2 4 ms
DLY Delay 16 1 ms
FLT Filter 4 1 ms
LIM Limit 4 4 ms
MAP Map 4 4 ms
MTD Multiply then Divide 4 4 ms
NVM Non-Volatile Memory 38 2 ms
PID Proportional Integral Derivative 2 4 ms
POT Potentiometer Input 4 4 ms
PWM Pulse Width Modulated Output 16 4 ms
RMP Ramp 4 1 ms
SCL Scaling 4 4 ms
SEL Selector 2-position switch 8 4 ms
SEL_4P Selector 4-position switch 8 32 ms
SW Switch Inputs (all) 1 4 ms
RTC Real Time Clock 1 4 ms
TMR Timers (hourmeters) 3 1 ms
1310 Vehicle Control System Users Manual Release Rev B Page 27 of 51
