APPENDIX C - SPE CIFICATIONS
APPENDIX C - Specifications
1310 Specifications
Nominal Input Voltage 24 – 48 volts
Electrical Isolation to case 500 VAC
Storage Ambient Temperature Range -50 to +90
o
C
Operation Ambient Temperature Range -40 to +85
o
C
Enclosure Protection Rating IP42
Weight 0.82 Kg
Dimensions 198 x 138 x 46 (mm) (l x w x h)
Model Number Voltage Outputs / Inputs Options
1310-5210 24-48v 8 output / 18 input*† RTC,
1310-5310 24-48v 16 output / 22 input* RTC, PV drivers**
* Encoder inputs can be used for an additional 4 inputs
** PV (Proportional Value) drivers are on outputs 1 and 2 and have current feedback
† Outputs 9 through 16 are available and Inputs 14,15,17 and 18 are not available.
1310 Vehicle Control System Users Manual Release Rev B Page 51 of 51
