Assembly instructions
The position of the roll holder support is not fi xed and its rear, lower and upper position may be adjusted. The
support is attached to the printer frame at four points, as shown in fi gure A.3.
REAR ATTACHMENT
LOWER ATTACHMENT
UPPER ATTACHMENT
(Fig.A.3)
