WEIGHT STACK BELT
ROUTING DETAIL
ARM ROTATATION/SPRING
CABLE ROUTING DETAIL
ARM CABLE ROUTING
58
BELT LENGTH
66.375”
36
36
35
35
CABLE ROUTING
THROUGH ARM
Service
Page 8-9
Cybex FT-360S Functional Trainer Owner’s Manual
