Cybex FT-360S Functional Trainer Owner’s Manual
Final Assembly
1. Visual Inspection (see step 1A).
Visually inspect the entire FT-360S. Be sure cables are properly installed, hardware is secure and A.
the weight stack is properly assembled.
Verify Caution Decal, part number 9100-348-4 is present and not damaged. See Figure 1 to B.
identify what the decal looks like and see Figure 2 for location.
Figure 1
Assembly
Page 6-13
Figure 11
Front
Back
Insert a guide rod through each hole of the template. C. NOTE: A guide rod can be anything that
fi ts through the weight stack hole, such as a weight stack selector pin.
Carefully align and rub decal onto weight plates.D.
Carefully remove front side, leaving numbers adhering to weight plates.E.
